MX-160 5-Axis Trunnion Machining Center
Simultaneous 5-Axis CNC for Aerospace, Medical & Complex Parts
Require Custom Specs or Quote?
Get factory-direct pricing and full technical support from our engineering team.
Request Instant Technical QuoteProduct Description
The MAXIMA MX-160 is a simultaneous 5-axis trunnion-style machining center engineered for complex, high-precision parts. With 18,000 RPM HSK63A spindle, ±0.003 mm positioning accuracy, and trunnion-table configuration, it excels at aerospace, medical, and mold-making applications.
Single-Setup Capability
5-axis machining eliminates multiple setups, reducing fixture costs and improving geometric accuracy. Complex turbine blades, impellers, orthopedic implants, and mold inserts are produced in a single operation with ±0.002 mm repeatability.
Trunnion Configuration Advantages
- Better chip clearance than tilting-head designs
- Higher rotary accuracy for precision work
- Larger part envelope accessibility
- Lower Z-axis load for tighter geometric tolerance
Controller Options
Choose FANUC 31i-B5 (high-end 5-axis with AI contour control), Siemens 840D sl (advanced multi-axis), or Heidenhain TNC 640 (preferred by mold & die makers). All support simultaneous 5-axis and 3+2 positioning.
Ideal Applications
Aerospace turbine components, impellers, orthopedic implants, surgical instruments, complex mold inserts, optical components, and precision prototyping.
Technical Specifications
| Parameter | Specification |
|---|---|
| Configuration | Trunnion table (tilting rotary) |
| Linear Axes (X/Y/Z) | 500 / 400 / 450 mm |
| Rotary Axis A (tilt) | -120° / +30° |
| Rotary Axis C (rotation) | 360° continuous |
| Spindle Speed | 18,000 RPM |
| Spindle Power | 22 kW |
| Spindle Taper | HSK63A |
| Max Table Diameter | Ø400 mm |
| Max Workpiece Weight (on trunnion) | 200 kg |
| Rapid Traverse (linear) | 30 m/min |
| Rotary Axis Speed | 50 rpm (A) / 100 rpm (C) |
| Tool Capacity | 30 armless type |
| Positioning Accuracy | ±0.003 mm |
| Repeatability | ±0.002 mm |
| Control System | FANUC 31i-B5 / Siemens 840D sl / Heidenhain TNC 640 |
| Through-Spindle Coolant | 70 bar |
| Machine Weight | 8,500 kg |
