SL-30 CNC Slant Bed LatheD
High-Precision CNC Slant Bed Lathe for Medium-Large Parts
Require Custom Specs or Quote?
Get factory-direct pricing and full technical support from our engineering team.
Request Instant Technical QuoteProduct Description
The MAXIMA SL-30 is a 45° slant-bed CNC lathe designed for medium-to-large turned parts. With Ø540 mm swing, 4,500 RPM integrated-motor spindle, and 12-station servo turret, it combines the rigidity for steel cutting with the speed for aluminum and brass production.
Slant Bed Advantages
The 45° slant bed promotes chip evacuation, improves tool access, and reduces thermal distortion. Integrated spindle motor (not belt-driven) eliminates vibration and improves surface finish, especially on long shafts.
Productivity Features
- 12-station servo-driven turret with 0.15-second single-step index
- Programmable MT5 tailstock with hydraulic quill
- Through-spindle coolant ready (70 bar optional)
- Compatible with FANUC / KUKA / ABB robots for automation
- MAX-CLOUD IoT predictive maintenance included
Ideal Applications
Automotive shafts, hydraulic cylinder rods, valve bodies, pump impellers, bushings, couplings, and aerospace shafts. Works with steel, stainless, brass, aluminum, and titanium (with high-pressure coolant option).
Technical Specifications
| Parameter | Specification |
|---|---|
| Configuration | Slant bed (45°) |
| Max Swing Over Bed | 540 mm |
| Max Turning Diameter | 380 mm |
| Max Turning Length | 600 mm |
| Chuck Size | 10" hydraulic (250 mm) |
| Bar Capacity | Ø52 mm |
| Spindle Speed | 4,500 RPM |
| Spindle Power | 15 kW |
| Spindle Bore | Ø62 mm |
| X/Z Axis Travel | 210 / 600 mm |
| Rapid Traverse | 24 m/min |
| Turret | 12-station servo-driven |
| Turret Index Time | 0.15 s (single step) |
| Positioning Accuracy (X/Z) | ±0.003 / ±0.004 mm |
| Repeatability | ±0.002 mm |
| Control System | FANUC 0i-TF Plus / Siemens 828D |
| Tailstock | MT5 (programmable quill) |
| Power Supply | AC 380V 50Hz |
| Machine Weight | 4,800 kg |
